| Technical Characteristics of the Cartridge | |||
|---|---|---|---|
| Locking torque | 6~8N.m | Rotation angle | 360° |
| Burst pressure | ≥2.5MPa | Working pressure | 0.1~1MPa |
| Maximum hot water temperature | 90°C | ||
| Tightness test | |||
| Atmospheric pressure | 0.8MPa | ||
| Life test | |||
| GB18145/EN817 | ≥30000Times | ASMEA112.18.1 | ≥15000Times |
| CERAMIC DISC | |||
| Flatness | ≤0.3μm | Surface roughness | 0.1-0.3μm |
| Hardness | ≥1000HV | Porosity of surface | 30-40% |
| FLOW RATE CHARAT | |||
